Engine Generation Open/Soundproof Type Power Diesel
HomeHome > Products > Gas Turbine Power Generation > Engine Generation Open/Soundproof Type Power Diesel
Engine Generation Open/Soundproof Type Power Diesel

Engine Generation Open/Soundproof Type Power Diesel

Overview Company Profile Kangwo jidian is a set of research and development, manufacturing, sales, service in the integr
Overview
Basic Info.
Model NO. Open Type Generator
Output Type AC Three Phase
Speed Speed
Conditions of Use Land Use
Usage Common Units, Standby Unit, Emergency Crew
Landuse Type of Unit Low Noise Automation Type
Excitation Mode AC Rotating Exciter
Rated Voltage 400V/230V
Rpm 1500/1800
Frequency 50Hz/60Hz
Rated Current 92A
Transport Package Customerized
Specification Standard size
Trademark Kangwo
Origin China
HS Code 8502120000
Production Capacity 300 Sets/Month
Product Description

Engine Generation Open/Soundproof Type Power Diesel


Engine Generation Open/Soundproof Type Power Diesel


Technical data

Prime Power

50KW/62.5KVA

Rated Voltage

400/230V

Frequency

50/60Hz

Power Factor

0.8(lagging)

The regulating rate of steady voltage

≤±0.5%

The regulating rate of instantaneous voltage

≤-15%/ +20%

The time of steady voltage

≤1.5sec

The waving rate of voltage

≤1.0%

The regulating rate of steady frequency

≤3%

The regulating rate of instantaneous frequency

≤±10%

The time of steady frequency

3sec

Dimension (L×W×H) (mm)

2900*1000*1800

Genset weight (kg)

2000

Diesel Engine

Brand

Model

1103A-33TG2

Number of Cylinders

4

Rotating Speed

1500/1800RPM

Cycle

Four stroke

Type

waste gas turbine boost,direct spurting type

Bore×Stroke(mm)

105*127

Displacement(L)

3.3

Lubricating Capacity(L)

8.3

Speed Governor

Mechincal

Cooling System

Water-cooled

Speed Stability (%)

≤5%

Fuel Consumption at 100% Load

211g/kw.h

Starting Method

DC24V Electrical starting

Alternator

Brand

Hengsheng

Model

HSJ224F

Number of Phase

3

Connecting Type

Three Phase and Four Lines

Number of Bearing

1

Grading Protection

IP22

Altitude

≤1000m

Exciter Type

Brushless (AVR automatic voltage regulating)

Insulation Class

H degree

Engine Generation Open/Soundproof Type Power Diesel

Engine Generation Open/Soundproof Type Power Diesel

Company Profile

Engine Generation Open/Soundproof Type Power Diesel


Kangwo jidian is a set of research and development, manufacturing, sales, service in the integrationof engine, generator set research and development manufacturers. The main Operating various typesof generating sets for industrial(pump station) use, Marine, power stations and other fields. Powercoverage: 80KW--2000KW. Its professional, efficient and grade of power products are widely usedin petroleum and petrochemical, mining, manufacturing, transportation, high-rise construction bankfinance, post and telecommunications, IT industry and military industry, and many other industries ofhigh power supply reliability requirements. Relying on the perfect and powerful marketing service system,the company′s products are sold all over the country and around the world.The company relies on a good commercial reputation and the development potential and shandongweichai, Shanghai dongfeng, wuxi vandy, daewoo, Rolls-Royce, Volvo, mercedes-Benz, cummins leroysomer, ABB, Stanford, marathon and other famous companies at home and abroad to establish long-termfriendly relations of cooperation. And become his OEM. Matching plants and special maintenance points.The company produces a complete set of generating units with common type mobile type, anti-sound type,self-starting generating set, three-remote generating set, ATS automatic switching screen, etc. Automaticparallel screen and other intelligent generating units, the unit adopts Chinese and English liquid crystalmodule, full digital display, with overspeed, oil temperature, water temperature and oil pressure automaticprotection system. Our technical service personnel can provide more accurate and effective pre-salesand after-sales technical services to users everywhere at any time.Different kinds of products are available in our company. We′re pleased to get your Inquiry and we willreply you as soon as possible. We stick to the principle of "quality first, service first, continuous improvementand innovation to meet the customers" for the management and "zero defect, zero complaints" as the qualityobjective.

FAQ

1
Q:What is your main products and applications?

A:Our main products are 4-cylinder/6-cylinder/12-cylinder diesel engine and diesel gensets.Our engine is usually used on "Power generation equipment, Industrial water pumps, Agricultural machinery,Marine and Ship, Engineering machinery, Vehicle & Special machinery",etc.2
Q:How soon will I get my engine after payment?
A:Our warehouse has sufficient regular sizes stocking, ready to deliery, and we have lots of raw materials storage,customer specifications can be arranged in a timely manner production, So the lead time within 7-10days for ordersunder 100units/order, delivery time will be 20-60days depends on the arrival ports.3
Q:When Can I get the price?
A:We will reply you within 24 hours after we get your inquiry, Or you could directly call us if you are urgent.4
Q: What is your MOQ of this item?
A:1 Set5
Q: Is it all right to make customer's own brand name?
A:We can be your OEM manufacture with your authorization of brand.6
Q: Where is your Loading Port?
A:Xiamen or others7
Q: What are your payment terms?
A:30% TT as deposit,70% TT before Shipment.8
Q: What is your company's available production capacity?
A:100 Sets per month.9
Q:What's the warranty time of diesel generators?
A:12 Months or 1000 working hours
